Air

Model Number Identification

RH1T/RH2T Series

44

Available Models at 115V A Voltage

RH1T2417STANAA

RH1T3617STANAA

RH1T3621MTANAA

RH1T4821STANAA

RH1T4824STANAA

RH1T6024STANAA

Available Models at 218V J Voltage

RH1T2417STANJA

RH1T3617STANJA

RH1T3621MTANJA

RH1T4821STANJA

RH1T4824STANJA

RH1T6024STANJA

RH2T2421MTANJA

RH2T3621MTANJA

RH2T4824MTANJA

RH2T6024STANJA

R H 1 T 24 17 S T A N A A ***

Option Code (see ADS-3803)

Blank = None

Minor Series

A = First

Voltage

A = 115/1/60

D = 480V/3/60

J = 208/240/1/60

Controls

C = Communicating

N = Non-Communicating

Major Series

A = First

Metering Device

T = TEV

E = EEV

P = Piston

Coil Efficiency

S = Standard

M= Medium

H = High

Width

17 = 17.5" [431.8 mm] (600-1200 CFM)

21 = 21" [533.4 mm] (800-1600 CFM)

24 = 24.5" [609.6 mm] (1400-1800 CFM)

Nominal Capacity

24 = 18,000 [5.27 kW]-24,000 [7.03 kW] BTU/H

36 = 30,000 [8.79 kW]-36,000 [10.55 kW] BTU/H

48 = 42,000 [12.31 kW]-48,000 [14.06 kW] BTU/H

60 = 60,000 [17.58 kW] BTU/H

Motor Type

T = Constant Torque (ECM)

Stages of Air Flow

1 = Single

2 = Two Stage

Product Category

H = Air Handler

Rheem

[ ] Designates Metric Conversions

Available Models at D Voltage

RH1T6024STANDA
